6 Key 50W Multifunctional MP3 Player

(0 review)

Quantity on Hand : 15
Skill Level : Assembled and Tested

Buy 10, Get 5% Off!
Buy 100, Get 10% Off!


39.95 39.95 USD 39.95


Not Available For Sale

  • WeightMajor
  • WeightMinor

This combination does not exist.

Add to cart
Button-Triggered Sound File Upload Terminal Block Connection Built-in Amplifier Headphone Audio Output Additional Memory Capable In Enclosure


  • 6 trigger inputs available and triggered by a negative pulse or GND.
  • The function/trigger mode of each input can be set individually through a configuration file.
  • Each input can store more than 1 sound file
  • Equipped with a high-quality audio decoder that is able to decode MP3 and WAV audio formats.
  • Built-in 8MB flash memory by default and supports max. 32GB micro SD card.
  • Able to update audio files through the micro USB port based on PC like using a USB flash drive.
  • Built-in 50 Watt mono class D amplifier and a stereo audio output jack.
  • 9-40V DC wide power input and stable performance.
  • Possible to drive a 10 Watt to 50 Watt speaker (depended on voltage input)
  • Adjustable sound volume through the potentiometer.
  • Industrial grade design and strong anti-jamming capability.
  • Dimensions: 105 x 64 x 23.5 (mm)

Technical Parameters:

  • Working voltage: 9-40V DC
  • Working current: ≤2000mA (Input: DC24V)
  • When connecting with a 50 Watt speaker, 24VDC and at least 2000mA power supply is required
  • Power Consumption: ≤50W
  • Flash memory size: 4MB
  • Audio format: MP3/WAV
