Interval Timer Kit

(0 review)

SKU : WST111
Quantity on Hand : 16
Skill Level : Kit - Basic Soldering Required
ROHS Compliant

Buy 10, Get 5% Off!
Buy 100, Get 10% Off!

8.95 8.950000000000001 USD 8.95

8.95

  • WeightMajor
  • WeightMinor

This combination does not exist.

Terms and Conditions

Share

Description: General purpose pulse - pause timer for various interval timer automations. For intermittent operation of circuits and equipment.

Features
  • Blinking light, warning light
  • Video/photo single frame shooting
  • Slide projector control
  • Miniature models applications
  • Automated testing
  • Automated aging tests
Specifications
  • Output relay with NO / NC* contact: 3A
  • Pulse time adjustable: between 0.5 and 5 sec.
  • Pause time adjustable: between 2.5 and 60 sec.
  • (Because of the NO / NC relay contacts, a pulse time of 2.5 to 60 sec and pause time of 0.5 to 5 sec. can also be obtained alternatively)
  • Power supply: 12V DC / 100mA
  • Dimensions: 1.6" x 3.4"
*NO = Normally Open, NC = Normally Closed

Documentation and Downloads
