TER-BAC temperature sensors are designed to detect temperature in the room spaces. The BACnet sensors have linear 0-10V signals outputs relating to the temperature, and for the optional light level, and BACnet MS/TP communication. TER-BAC BACnet sensors have also a digital input, a resistive input and two digital outputs.
TER-BAC BACnet temperature sensors can be installed on wall surface or on a wall mounting box in dry indoor environment. The TER-BAC BACnet temperature sensors come with a number of options such as display, active setpoint, occupancy detection, lux level measurement, push button and additional digital/resistive input.
The TER-BAC BACnet temperature sensors can also operate as temperature controllers modulating analogue output of the sensor. The setpoint is supplied either via the network or from the setpoint potentiometer (if -SP option fitted).
- BACnet MS/TP Communication with Device Discovery
- Large Range of Options to Suit Any Applications
- Built-In Controller Functionality for Temperature and Light Control
- Can act as a BACnet Network IO-Module as well as BACnet Temperature Sensor
- Attractive Wall Mounted Room Enclosure (for UK/European/US mounting)
NOTE: This product will need the SXS-530 for configuration. Ocean Controls can provide configuration service for this device (SXS-999).
Features:
- Power Supply: 15..35Vdc / 15..30Vac <85mA
- Outputs: Optional 2 x 0..10Vdc/4..20mA (relative humidity / temperature)
- Humidity Range: 0..100%rH
- Accuracy: ±3%rH (for 20..80%rH)
- Temperature Range: -50 to +50°C, adjustable with optional display
- Temp Accuracy: ±0.5°C
- Protocol: BACnet MS/TP or Modbus RTU/ASCII
- Addressing: 1..127,
- Baud Rate: 9k6/19k2/38k4/57k6
- Perm. Ambient Temp: -20,,+70°C
- Cable Gland: M16
- Terminals: Spring Terminals 0.2..1.5mm2
- Protection Class: IP65 Including Seal
- Enclosure: Plastics Grey/Blue
- Dimensions: W86 x H120 x D29mm
