High Accuracy Digital Compass with 4-20mA Output 24V DC Powered

https://electronics123.odoo.com/web/image/product.template/9032/image_1920?unique=b6a0983
(0 review)

SKU : SRS-220
Quantity on Hand : 0
Skill Level : Assembled and Tested

Buy 10, Get 5% Off!
Buy 100, Get 10% Off!

SRS-220

799.00 799.0 USD 799.00

799.00

Not Available For Sale

  • WeightMajor
  • WeightMinor

This combination does not exist.

Add to cart


Description: The HCM508BA1 is a high end 3D digital compass, capable of resolving magnetic north with better than 0.5 degree accuracy and 0.1 degree resolution. Patented 3-axis flux-gate technology uses hard magnetic and soft magnetic algorithms to maintain course accuracy over a wide range of tilt angles, even in magnetically noisy environments.

The unit is housed in a rugged aluminium enclosure rated to IP67. All electronics are military grade. Operating temperature range -40°C to 85°C.

Package contents: HCM508 compass, wiring diagram including pinout, four pin connector plug on 30 cm flying leads.

Features:

  • Heading accuracy: 0.3 - 0.5°

  • Tilt angle resolution: 0.1°

  • Tilt angle accuracy: 0.2°

  • Roll Angle: ±180°

  • Output: 4 to 20 mA

  • Size: 125L x 22W x 24H mm

  • Power: 24V DC
