Dual Axis Inclinometer 45 Degrees - 4-20mA Output

(0 review)

SKU : SRS-077
Quantity on Hand : 0
Skill Level : Assembled and Tested
ROHS Compliant

Buy 10, Get 5% Off!
Buy 100, Get 10% Off!

129.00 129.0 USD 129.00

129.00

  • WeightMajor
  • WeightMinor

This combination does not exist.

Terms and Conditions

Description: The MCA428T-45-A1 dual-axis inclinometer uses the latest MEMS technology to sense the angle of the device in two axes. The sensor mounts flat and provides an analog current output.

Specifications:

  • Power supply: 9 to 36 V DC

  • Range: -45 to 45 º on both axes

  • Accuracy: 0.5 º

  • Resolution: 0.1 º

  • Response time: 0.05 sec

  • Wide operating temperature: -40 to 85 °C

  • Output: 4 - 20 mA (current)

  • Dual axis inclinometer

  • IP66 rated

  • Rugged casing

  • Shockproof > 3500g

  • Dimensions: 61 × 35 × 21 mm

Documentation and Downloads
