Mean Well DDR-15G-24 9~36V Input, 24V/0.63A

(0 review)

SKU : PDC-1014
Quantity on Hand : 1
Skill Level : Assembled and Tested

Buy 10, Get 5% Off!
Buy 100, Get 10% Off!

38.95 38.95 USD 38.95

38.95

  • WeightMajor
  • WeightMinor

This combination does not exist.

Terms and Conditions

Description:

These regulated output, switching, isolated DC-DC converters are useful for converting one DC voltage to another. They can be used to create one voltage rail from another or to give a stable voltage from a fluctuating source. They can provide regulated voltage out to power sensitive electronics from solar, battery or automotive sources.

  • MEAN WELL DDR-15G-24 DC/DC converter DIN rail type
  • Ultra wide 4:1 input voltage range
  • Operating temperature range: -40~+85°C
  • 3000Vdc I/O isolation
  • Adjustable DC output +/-10%
  • No minimum load required
  • Slim case width design
  • Dimensions:17.5 x 90 x 54mm
  • Convection cooled
  • Protections: short circuit / over load / over voltage / input reverse polarity / input under voltage protection
  • MEAN WELL 3 year warranty
  • CE certifications

Features:

    • Output voltage: 24 VDC
    • Rated current: 0.63 A
    • Power supply: 9 - 36 VDC
    • Efficiency: 86%
    • Protection: Overload, Over voltage , reverse polarity, under voltage
    • Dimensions: 17.5*90*54.5 mm

Documentation and Downloads
