Features:
- 14 different functions including timers, switching, flashing, interval, and random switching
- Two pre-programmed delays
- Learning mode for delays of 2s up to 12 days
- Push-button control
- EEPROM for delay time storage in case of power failure
- On-board transient filter for the relay contacts
- Suitable for control of incandescent lighting, halogen lighting, fluorescent lighting, fans, valves, buzzers, etc.
Specifications:
- Operating voltages: 9-12V AC or 12V DC
- max. load: 5A (1100W/230V)
- Dimensions pcb: 3.4" x 1.5" x 1.0"
