Features:
Family: LM386
- Minimum Single Supply Voltage : 4V
- Typical Single Supply Voltage: 5V/9V
- Maximum Single Supply Voltage: 12V
- Maximum Operating Temperature: 70°C
- Amplifier Type: Cla Featuresss-AB
- Output Type: 1-Channel Mono
- Maximum Load Resistance: 32 Ohm
- Supplier_Package : MDIP
- Maximum Quiescent Current: 8mA@6V
- Product Length: 9.27mm
- Total Harmonic Distortion Noise : 0.2%@8 Ohm @125mW
- Maximum Input Bias Current: 0.25uA(Typ)@6V
- Typical Output Power x Channels @ Load: 0.325Wx1@8Ohm
- Typical PSRR: 50dB
- Typical Quiescent Current: 4mA@6V
- Maximum Power Dissipation: 1250mW
- Rail to Rail: No
- Minimum Operating Temperature: 0°C
- Function: Speaker
- Mounting Through Hole
- Pin Count: 8
- Product Width: 6.35mm
- Product Height: 3.3mm
- Power Supply Type: Single
- Product Type: Audio Amplifier
- Typical Voltage Gain: 46dB
- Input Signal Type: Single
- Output Signal Type: Single
| Specification | Value |
|---|---|
| Supplier Package | MDIP |
| Amplifier Type | Class-AB |
| Input Signal Type | Single |
| Output Type | 1-Channel Mono |
| Power Supply Type | Single |
| Minimum Single Supply Voltage | 4V |
| Output Signal Type | Single |
| Typical Single Supply Voltage | 5V|9V |
| Maximum Single Supply Voltage | 12V |
| Maximum Input Bias Current | 0.25uA(Typ)@6V |
| Maximum Load Resistance | 32Ohm |
| Maximum Power Dissipation | 1250mW |
| Maximum Quiescent Current | 8mA@6V |
| Typical Output Power x Channels @ Load | 0.325Wx1@8Ohm |
| Typical PSRR | 50dB |
| Typical Quiescent Current | 4mA@6V |
| Rail to Rail | No |
| Total Harmonic Distortion Noise | 0.2%@8Ohm@125mW |
| Minimum Operating Temperature | 0°C |
| Maximum Operating Temperature | 70°C |
| Mounting | Through Hole |
| Packaging | Rail |
| Pin_Count | 8 |
| Product Height | 3.3mm |
| Family | LM386 |
| Product Type | Audio Amplifier |
| Product Width | 6.35mm |
| Product Length | 9.27mm |
| Typical Voltage Gain | 46dB |
