Description: Need to measure the temperature of a liquid or gas. This sensor is equipped with an RTD PT100 temperature sensor embedded into a 6x40mm stainless steel probe and comes with a 3metre cable and 3 wires at the end. The cable is a 3.3mm 3 wire grey round sheath cable. Operating temperature range:-55°C to +125°C (-67F to +257F)
Features:
- Temperature Range: -55 to 125 °C (-67F to +257F)
- Accuracy (-10 to 85 °C): ±0.5 °C
- Accuracy (-55 to 125 °C): ±2.0 °C
- Probe Dimensions: 6 x 40 mm
- Cable Dimensions: 3 m x Ø 3.3 mm
- Cable End: 3 wires
