Recordable MP3 Sound Module for Toys / Gift Boxes (Push Switch) V1.1
Buy 10, Get 5% Off!
Buy 100, Get 10% Off!
Built-in a high-quality MP3 decoder chip.
Incorporated with a 4MB (32Mbits) flash memory for the storage device.
Works with most Windows, Mac, and Linux systems
Update MP3 file easily through the micro USB port based on PC.
Uses a momentary push button to play the sound file.
When the button is pressed, the module plays the sound one time and stops (default mode).
Equipped with a 0.5W 8ohm speaker.
Low standby current and clear sound output.
3pcs AAA batteries for the power supply.
PCB size: 32mmx22mm
Working voltage: 3.7V to 5V DC
Working current: ≤100mA (Input: 4.5V DC)
Quiescent Current: 0mA
Power Consumption: ≤0.5W
Flash memory size: 4MBytes (32Mbits)
Audio format: MP3
When the momentary push button is pressed it plays the sound one time and then stops.
Pushing the button during playback restart playback of the message from the beginning.
After playback is finished pushing button will play sound again.
Message CANNOT be looped by toggling switch and holding in on position.
The other trigger settings referred to in the Datasheet is NOT user selectable. It requires a customized unit. Minimum order quantity for that is 500 units. Contact us for a quote.
