This split-core Hall effect current transducer converts a DC input current of 0 to 100 A into a load-independent 4-20 mA DC output signal. Use it to monitor current in solar installations or battery charging and discharging; the 4-20 mA signal is easy to connect to a PLC or remote telemetry unit.
The transducer offers full galvanic isolation between input and output, high accuracy, low temperature drift and a wide operating temperature range.
- Input: 0 to 100 A DC
- Output: 4 to 20 mA DC
- Power supply: 24 VDC
- Accuracy: within 1%
- Isolation (input/output): at least 6000 VDC for 1 min
- Thermal drift: 600 ppm
- Mounting: screw
- Dimensions: 73 x 25 x 74 mm
