1/3 B/W Camera Mod M3186A (f3.7F2.0) EIA

  • WeightMajor
  • WeightMinor

9.95 9.95 9.950000000000001 USD


This combination does not exist.

Add to Cart

SKU : BB013
Quantity on Hand : 9
Skill Level : Assembled and Tested
ROHS Compliant

Buy 10, Get 5% Off!
Buy 100, Get 10% Off!

30-day money-back guarantee
Free Shipping in the U.S. on Orders over $75
We offer worldwide shipping as well
Buy now and choose from several shipping methods

Terms and Conditions

Description: This is a family of products based on the most advanced CMOS mixed signal technology. It integrates image array, signal processing, timing and control circuitry, all on a single chip, enabling all aspects of B/W video camera application. It is ideal for applications requiring a small footprint, low power and low cost.


  • Small size 29 x 29 mm

  • Wide operation voltage 8-15v

  • Lens f3.7mm f2.0

  • Low power consumption (<200mW)

  • Direct connect to standard video monitor

  • On-chip auto exposure control

  • Gamma correction - 0.45/1.0

  • Auto gain control-18db

  • Automatic black level calibration

  • Lens (included): f3.7mm, F2.0 FOV 65deg x 50deg (wide FOV)
